Product Details
● Type: 3 Pole XLR Female Connector Chassis Panel Mount XLR Socket ● Material: Plastic, Metal ● Can be applied on microphone connections/audio electronics, amplifiers and cabling applications. ● Available in 3, 4, 5, 6 and 7 pin configuration with silver or gold plated contacts ● Color: Black, Silver ToneSpecification
| Product Name | 3 Pole XLR Female Connector Chassis Panel Mount XLR Socket |
| Model | CT3-08HFA |
| Pin | 3 PIN |
| Contact Resistance | ≤0.2 MΩ |
| Insulation Resistance | ≥100 MΩ |
| Withstand Voltage | 1500V, AC/min |
| Terminal Strength | ≥30 N |
| Rated Load | 250V DC 1.0A |
| Temperature | -30 ~ +80 ℃ |
| Life | 5000 Time |
